Local Console Connectors
2x USB Type-A Female (White)
1x HDB-15 Female (Blue)
1x Mini Stereo Jack Female (Green)
1x Mini Stereo Jack Female (Pink)
1x DB-9 Female (Black)
1x RJ-45 Female
1x DC Jack

Local CPU Connectors
1x SPHD-15 Female (Yellow)
1x Mini Stereo Jack Female (Green)
1x Mini Stereo Jack Female (Pink)

Remote Console Connectors
2x USB Type-A Female (White)
1x HDB-15 Female (Blue)
1x Mini Stereo Jack Female (Green)
1x Mini Stereo Jack Female (Pink)
1x DB-9 Male (Black)
1x RJ-45 Female
1x DC Jack

LEDs
• Local: Green (Local unit)
• Remote: Green (Local unit); Green (Remote unit)
• Link: Green (Remote unit)
• Picture Compensation: Orange (Remote unit)

Push-Buttons
1x Operating Mode Selection (Local unit)
2x Picture Compensation (Remote unit)

Operations
• Keyboard/Mouse Emulation: USB
• Video Resolution: 1920x1200 @ 60Hz at 100 feet (30 m); 1600x1200 @ 60Hz at 492 feet (150 m); 1280x1024 @ 60Hz at 656 feet (200 m)

Environment/Power
• Storage Temperature: -20~60˚C
• Operation Temperature: 0~50˚C
• Humidity: 0~80% RH, Non-condensing
• Power Consumption: DC5.3V/2.68W Local unit; DC5.3V/3.6W Remote unit

Physical
• Case: Metal
• Weight: 1.04 lb (0.47 kg) each unit
• Local unit Dimensions (L x W x H): 7.95 x 3.4 x 0.98 in. (20.2 x 8.63 x 2.5 cm)
• Remote unit Dimensions (L x W x H): 7.95 x 3.15 x 0.98 in. (20.2 x 8.01 x 2.5 cm)
