USB-C to HDMI Dual Adapter - 2-Port MST Hub

Model No. MSTCDP122HD In stock

USB-C to HDMI Dual Adapter - 2-Port MST Hub
Buy this item and earn 75 ClubPoints.

MSTCDP122HD: Connect two 4K HDMI screens to a single USB Type-C port on your laptop

2-port MST hub; Thunderbolt 3 compatible

• Maximize your productivity by connecting two independent displays to your computer using this MST hub
• Connect your USB-C computer to two HDMI displays such as televisions, monitors or projectors
• Connect to almost any television, monitor or projector with the support of low-cost adapters
• Hassle-free connection with the reversible USB-C connector
• Thunderbolt 3 port compatible

This MST hub lets you connect two HDMI® monitors to your USB-C™ computer. MST works on any Windows® device that supports DP Alt Mode over USB Type-C™, such as models of Dell Precision™ and Dell XPS™ laptops and ASUS® ROG GL752. The MST hub also works with Thunderbolt™ 3 ports to provide Thunderbolt 3 to dual HDMI conversion.

The USB-C HDMI hub is powered by the USB-C port, so you don't require an additional power adapter. This adapter works with USB Type-C devices that pass a DisplayPort video signal.

Increase your productivity with multiple monitors
The newest generations of laptops are more portable than ever. But, this could mean that you’re left with fewer video outputs and confined to your laptop's integrated screen. This USB-C MST hub solves these problems by letting you connect two independent HDMI displays through a USB-C port on your computer, which makes multitasking much easier.


Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display. This makes it easier to multitask and increase your productivity -- perfect for creating a hot-desk solution with a wireless keyboard and mouse peripheral set.

The hub also lets you mirror the same image onto multiple displays, for remote viewing applications such as digital signage.

Astonishing picture quality that won't drain your system resources
MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. 4K is supported by the latest A/V devices and offers four times the resolution of 1080p. Plus, because the MST hub can output high-definition 1080p, it's perfect for all high-resolution applications such as graphic design and CAD drawing.

Works with any monitor, television or projector
With this MST hub, you can use separate HDMI video adapters to connect DisplayPort, VGA or DVI displays, for compatibility with all of your existing monitors. The hub supports DisplayPort 1.2 enabled systems, for seamless integration with your existing video equipment.

• Connect additional displays to your USB-C device
• Use one screen for referencing data, such as websites, while composing your documents on another screen
• Connect your USB-C device supporting DP alt mode to two high-resolution displays at your workstation
• Create a panoramic video wall for HDMI digital signage applications
• Edit images, video or audio clips across two additional displays in any orientation or resolution
• Span a spreadsheet or worksheet across two additional displays, to avoid side-scrolling

• Your USB-C equipped device must support video (DP alt mode) to work with this adapter.
• MST shares 21.6Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup. Exceeding 100% will reduce functionality.
• Average resolution bandwidth allocation:
1920x1080 (Full HD 1080p) @ 60hz - 22%
1920x1200 @ 60hz - 30%
2560x1440 @ 60hz - 35%
2560x1600 @ 60hz - 38%
3840x2160 (4K Ultra-HD) @ 30hz - 38%
