Model No. MXU-88S In stock

Buy this item and earn 4,124 ClubPoints.

8x8 4K HDMI/USB 2.0 matrix switch

access and control up to eight computers with 4K HDMI and transparent USB 2.0 devices from up to eight connected consoles

MXU-88 is a 8x8 HDMI and USB 2.0 matrix switch. It lets up to eight users easily access and control eight computers and USB 2.0 devices from eight consoles, each equipped with transparent USB peripherals such as keyboards, mice, hard-drives, scanners, as well as 4K-compatible HDMI monitors.

Perfect for control rooms or group video editing suites, MXU-88 excels at expediting workflow by offering control of remote systems via USB peripherals like keyboards, mice, and more with the advantage of 4K-ready HDMI display support.

Controlling MXU-88 is easy thanks to SmartAVI's simple-yet-robust design. The two-button front panel control interface allows users to switch between connected systems and devices at the press of a button. Furthermore, MXU-88 features a web-based control interface that offers comprehensive command of connected displays and peripherals via an Ethernet connection, which lets you visualize connections between consoles and controlled computers and navigate between them.

MXU-88 is capable of ultra-high detail resolutions up to 4K (3840x2160 @ 30Hz) on HDMI monitors. The switch's 4K capabilities makes it an essential component in various real-world applications including control room supervision, post-production, group-based digital design work, large-scale server management, and more!

Controlling MXU-88
• Front-panel buttons: Two push buttons for switching between sources, systems, and connected devices
• Web console: Control switching, display settings, peripherals, and more from MXU-88 web-based control interface

MXU-88 excels in multi-user settings, and works well in various real-world applications such as remote project supervision or group-based video editing endeavors. MXU-88 is an ideal solution for medical, industrial, studio and defense applications, where it is not practical or safe to have multiple workstations in close proximity to each other. An operator can switch to any connected computer from any connected station with ease.

Features and Benefits
• 8x HDMI inputs and 8x HDMI outputs with resolutions up to 4K (3840x2160 @ 30Hz)
• 8x USB 2.0 Type-B inputs (for computers)
• 16x USB 2.0 Type-A outputs (for consoles)
• Supports digital audio over HDMI
• Supports DVI-D with adapters
• Supports USB keyboard-mouse control (with no emulation)
• Supports USB peripheral devices (external hard-drives, scanners, printers, etc.)
• Simple two-button front panel control with LCD status display
• Full web-based control console over Ethernet
• Learns and stores EDID information
• HDMI 1.4 and HDCP compliant
• Control Sun, Mac, or PC computers from consoles
• Plug-and-play for immediate use

Package Includes
1x MXU-88 8x8 HDMI/USB 2.0 matrix switch
1x PS12VDC5A power supply
1 Quick start and installation guide
Cables not included

Required Cables (per port)
1x HDMI, male-male or HDMI-DVI, male-male
1x USB, Type-A to Type-B
