Super-High-Resolution VGA Video Splitters

Super-High-Resolution VGA Video Splitters

2- 4- and 8-port 450 Mhz VGA video splitters, supporting analog video resolution up to 1920x1440 and signal boosting up to 213 feet
Read more below...


1) VS132A Model No. VS132A Usually ships in 7-10 business days or less

$47.25 MSRP: $63.00 - You save $15.75

2) VS134A Model No. VS134A Usually ships in 7-10 business days or less

$71.99 MSRP: $96.00 - You save $24.01

3) VS138A Model No. VS138A Usually ships in 7-10 business days or less


$104.99 MSRP: $140.00 - You save $35.01

2- 4- and 8-port VGA video splitters

with 450 MHz video bandwidth and signal boosting up to 213 Feet

ATEN's super-high-resolution video splitters are signal boosters and splitters that are used to take video input from a single source and direct it to two, four or eight video outputs for monitors using analog signals.

The signal boost allows you to not only split the signal but to extend the distance so that you can send the signal to about 210 feet. This is no mean feat, your average VGA card, over a standard VGA cable, send a clear VGA signal approximately 25 feet. This makes public broadcasts from a single computer very feasible. If you want to display the same information on many monitors at once, such as in a classroom environment, or at a demonstration, these products performs incredibly well.

Bandwidth is the term that is used to describe the signal capacity of these units. In general, bandwidth is directly proportional to the amount of data transmitted per unit of time. Specifically, in analog signals, bandwidth is the difference between the highest-frequency and the lowest frequency components of a givin signal. For example a voice telephone signal has a bandwidth of 3000 Hz (or 3000 cycles per second), where an analog TV signal has a bandwidth of approximately 6MHz (or 6 million cycles per second) which is approximately 2000 times greater than a simple voice phone call.

ATEN's super-high-resolution video splitters support a bandwidth of 450MHz (which is 450 million cycles per second) and that is 60 times greater than a simple TV signal. This huge bandwidth allows for the transmission of large amounts of information at a very high rate of speed, and thus you can use the very high resolution setting of 1920 x 1440 in 24 or 32 bit true color mode at a refresh rate of 70Hz.
