VM6809H

Model No. VM6809H Usually ships in 7-10 business days or less

VM6809H
Buy this item and earn 6,654 ClubPoints.

8x9 4K Ultra-HD HDMI matrix switch and video wall

with scaling and fast seamless switching


• 8x9 HDMI input/output connections
• Seamless Switch™ features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*
• HDMI (3D, Deep color, 4K)
• HDCP 2.2 compatible
• Multiple Control Methods - system management via front-panel pushbuttons, RS-232 control, and Web GUI/Telnet via Ethernet connections
• Video Wall - VM6809H is built-in with video wall functionality that allows you to customize display layouts using the intuitive web GUI which has won the Red Dot Interface
Design award. Through the profile setup that comes with up to 17 connection profiles, multiple displays can be easily configured to show video as a single large screen in various layouts - to see "what you want, how you want it".
• 4K scaler - VM6809H is equipped with a high-performance 4K scaling engine that converts various input resolutions into the display's native resolution, giving viewers the best picture and video quality. Inputs with low resolutions are scaled perfectly to the best fit, so that video playback is smooth and pleasant. In addition, the premium scaling engine offers a range of aspect settings that automatically adjusts the picture ratio for maximum viewing comfort.
• Smooth and seamless viewing experience - VM6809H's built-in FPGA design unifies video formats and provides continuous video streams, real-time switching, and stable signal transmissions. It is capable of high-speed switching between all input and output ports - supporting TMDS high data transfer rates of up to 4K @ 60 Hz to minimize latency.

ATEN's VM6809H 4K HDMI matrix switch with scaler is compatible with the two latest 4K video resolution standards: 3840x2160 and 4096x2160. VM6809H provides powerful HD processing to produce 4K resolutions across nine displays with crystal clear images.

VM6809H supports 4K @ 60Hz, HDMI 2.0** and HDCP 2.2 and features seamless switching that employs a FPGA matrix architecture that ensures continuous video streams, real-time control and stable signal transmissions. With a built-in high-performance scaler, VM6809H easily converts various input resolutions into various output display resolutions, giving viewers the best video and picture quality across all displays. The switch integrates video wall functionality with an easy to use web GUI that lets you create 17 connection profiles that can be customized into different video wall layouts.

VM6809H is an ideal solution for applications that require multiple HDMI displays with multiple HDMI sources to be conveniently setup - such as for stage presentations, digital classroom, video conference rooms and any installation that requires real-time reporting.

Smooth and Seamless Viewing Experience
VM6809H's built-in FPGA design unifi es video formats and provides continuous video streams, real-time switching and stable signal transmissions. It is capable of high-speed switching between all input and output ports - supporting TMDS high data transfer rates of up to 4K @ 60Hz to minimize latency.

Video Wall
VM6809H is equipped with video wall functionality integrated through an easy to use web GUI. The video wall setup provides up to 8 connection profiles that you can customize into layouts using a simple point and click web interface. Video walls allow you to setup multiple displays that are confi gured to form and show video as a single large screen in various layouts - to see what you want, how you want.

System Operation
• Browser Graphical User Interface (GUI)
• Serial controller
• Ethernet
• Telnet
• Front panel LCD display and pushbuttons

Features and Benefits
• 8x9 HDMI input/output connections
• Multiple means for system operation including front-panel pushbuttons, bi-directional RS-232 serial controller / Ethernet connections for web GUI or Telnet
• 4K scaler - features a 4K video scaling function to convert input resolutions to the display's native resolutions
• Seamless Switch™ - features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*
• Video Wall - allows you to create custom video wall layouts via intuitive web GUI*
• EDID Expert - selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolutions across different screens
• 4K video wall using lower-resolution displays - split a 4K signal to nine 1080p displays or nine 720p displays to form a 2x2 or 3x3 4K video wall
• FrameSync - prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate
• HDMI (3D, Deep color, 4K)
• HDCP 2.2 compatible
• Consumer Electronics Control (CEC) supported*
• Audio-enabled, HDMI audio can be extracted to stereo audio
• ESD protection for HDMI
• Firmware upgradable
• Rack-mountable (1U design)

Package Contents
1x VM6809H 8x9 4K HDMI Matrix Switch with Scaler
1x Power Cord
1x Rack Mounting Kit
1x User Instructions
Cables not included

Required Cables (per Port)
1x HDMI, male-male (input)
1x HDMI, male-male (output)

* 1. When Seamless Switch™ is enabled, 3D, Deep Color, or interlace (i.e., 1080i) formats will not be supported. To use these formats, make sure to disable Seamless Switch™.
2. Videos may not display within range when Seamless Switch™ or Video Wall is enabled, in which case please adjust the display settings on your device.
** HDMI 2.0 supports 3840 x 2160 @ 30 Hz (4:4:4), 3840 x 2160 @ 60 Hz (4:2:0), 4096 x 2160 @ 30 Hz (4:4:4), 4096 x 2160 @ 60 Hz (4:2:0) resolutions.
