CS1842

Model No. CS1842 In stock

CS1842
Buy this item and earn 419 ClubPoints.

2-port USB 3.0 4K HDMI dual-display KVMP™ switch

• Superior video quality – 4096x2160 @ 60Hz and 3840x2160 @ 60Hz; 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates
• Quad-Display – connect two CS1842 units for a quad-display setup controlled by one operator
• Supports Video DynaSync™
• Computer selection via pushbuttons, hotkeys, mouse, remote port selector, and RS-232 commands

CS1842 2-port USB 3.0 4K HDMI dual-display KVMP™ switch combines KVM switch with HDMI video interface and 2-port USB 3.1 Gen 1 hub.

ATEN CS1842 dual-display KVMP™ switch presents a valuable solution for desktop workstation with instant and effortless access to two HDMI interface computers from a single USB keyboard, mouse and two HDMI monitors. To meet users' needs, CS1842 is compliant with HDMI 2.0 standard and supports superior video quality up to 4K DCI (4096x2160 @ 60Hz), offering the most stunning and vivid visuals.

The HDMI interface provides 4K Ultra-HD @ 60Hz and 4K DCI @ 60Hz resolution that displays the most vivid high-definition images available while producing premium sound for music, movies, and games.

CS1842 allows users to access two HDMI computers from a single USB keyboard, USB mouse and two HDMI monitors. CS1842 also supports quad-display by connecting two dual-display KVM switches.

In addition, with patented ATEN technology – Video DynaSync™, CS1842 provides optimized display resolution and accelerates switching between systems. Considering immediate data sharing, a built-in USB 3.1 Gen 1 hub delivers data transfer rates up to 5 Gbps, allowing you to speed up operations and share USB peripherals efficiently.

CS1842For requirements of more displays to monitor, users can daisy-chain two CS1842 for up to four displays to multitask easily and process tremendous information. Besides, a remote port selector is available for quick and streamlined port selection apart from pushbuttons, hotkeys and mouse port switching.

In addition to the front panel pushbuttons, hotkeys, mouse port-switching, and remote port selector functionality, CS1842 offers serial commands to help switch ports and configure device settings.

A Power On Detection feature also ensures that if one computer is powered off, CS1842 will automatically switch ports to the next powered-on computer.

With a built-in USB 3.1 Gen 1 hub, CS1842 provides SuperSpeed 5 Gbps transfer rates to all connected USB peripherals. The unit's independent (asynchronous) switching feature, allows the KVM focus to be on one computer while the USB peripheral focus is on another computer. This eliminates the need to purchase a separate USB hub or stand-alone peripheral sharer – such as a print server, modem splitter, etc.

Featuring an unbeatable combination of ultra high 4K resolutions, a next generation USB 3.1 Gen 1 hub and enhanced, user-friendly operations, CS1842 delivers the latest innovations in desktop KVM switching technology. As a feature-rich KVM switch, CS1842 is especially suitable for users who need to perform multiple tasks smoothly at CGI work, graphic design, video post production, and CAD engineering.

Features and Benefits
• One USB keyboard, mouse and two HDMI monitors control two HDMI computers and share two USB peripherals
• Supports Quad Display by connecting two dual-display KVM switches
• Video DynaSync™ – An exclusive ATEN technology that eliminates bootup display problems and optimizes the resolution when switching among different sources
• Supports superior video quality – 4K Ultra-HD (3840x2160 @ 60Hz) and 4K DCI (4096x2160 @ 60Hz)
• Computer selection via pushbuttons, hotkeys, mouse1, remote port selector, and RS-232 commands2
• Built-in 2- port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates
• Supports console keyboard emulation/bypass feature
• Supports console mouse emulation/bypass feature
• Independent switching of KVM, USB peripheral, and audio focus3
• Multilingual keyboard mapping - supports English, Japanese, French, and German keyboards
• HDMI 2.0 compliant, HDCP 2.2 compliant
• Supports HD audio3
• Power on detection – if a computer is powered off, CS1842 automatically switches to the next powered-on computer
• Hot pluggable – add or remove computers without powering down the switch
• Sun and Mac keyboard support and emulation4
• Auto Scan Mode for monitoring all computers
• Firmware upgradeable
• Supports N-key Rollover5 (NKRO) – Permits collision-free keying

Package Contents
1x CS1842 2-port USB 3.0 4K HDMI dual-display KVMP™ switch
4x HDMI 2.0 Cables
2x USB 3.0 Cables
2x Speaker Cables
2x Microphone Cables
1x Power Adapter
1x Remote Port Selector
1x User Instructions

Notes
1. Mouse port switching is only supported under mouse emulation mode and by USB 3-key wheel mice.
2. Slide the DCC switch to the s position to allow the KVM switch to receive RS-232 commands via an RJ-45-to-DB-9 cable. Please refer to the CS1842/CS1842 user manual.
3. HD audio through HDMI channel cannot be switched independently.
4. PC keyboard combinations emulate Mac keyboards. Mac keyboards only work with their own operating system.
5. N-key Rollover supports up to 15 simultaneous keystrokes.
