4-port multiview DisplayPort* and/or HDMI* KVM switch

for displaying video from 4 computers on one (or two) screens and sharing USB 3.0 peripherals

Vertiv™ Avocent^® MultiViewer KVM switch provides full windowing capability, with each target PC displayed in a separate window and all-on-one (or two) monitor/display. With a dual console-screen, Vertiv™ Avocent^® MultiViewer KVM switch provides the user access of up to 4 computers either on single or dual monitors.

With cursor navigation switching (CNS), the user can quickly and seamlessly switch across multiple computers with a single mouse by simply moving the mouse across window borders, saving time and expense through a reduction in KVM switch peripherals.

Through the use of an all new video port, SVMV240DPH accepts either an HDMI or DisplayPort connector cable.

SVMV240DPH MultiViewer KVM switch is ideal for environments where monitoring and managing multiple active computers. The MultiViewer's window management capabilities allow for greater ease of use, with up to 4 computers on a single screen and features such as tiling, windowing, and touch screen.

Features and Benefits
• Simultaneously view multiple computers on a single monitor (or two monitors with different video layouts)
• Provides flexible multiple screen layout options for users: tile, scale, PIP or custom
• Enhances ability to multitask by keeping multiple critical systems in the user's field of vision
• Works with HDMI and DisplayPort by use of a universal video port, affording users with flexible display options
• Universal video connectors - support either HDMI or DisplayPort on the same physical video input ports (DVI-D supported with HDMI-to-DVI-D cable)
• Native video supports up to Ultra-HD 4K at 30Hz
• Flexible screen/window layout options with zero lag
• Cursor navigation switching (CNS) seamlessly transitions keyboard and mouse control between computers when moving the cursor across screen borders
• Touch screen support
• Switched USB accessory port for mass storage devices, cameras, printers, etc.
• Freeze USB accessory channel – independently locks USB accessory channel to a specific computer
• Freeze audio channel – independently locks the audio channel to a computer

In the Box
1x SVMV240DPH switch
1x Power cord
• Cables are not included

Required Cables (per port)
1x DisplayPort KVM Cable or HDMI KVM Cable
or
1x DisplayPort, male-male or HDMI, male-male
1x USB, Type-A to Type-B (for keyboard/mouse)
1x USB, Type-A to Type-B (for USB peripherals)
2x 3.5mm audio cables, male-male

* Notes
1) Each connected computer's video interface may be either HDMI or DisplayPort.
2) One computer may use an HDMI video connection to the switch while another computer may use a DisplayPort video connection.
3) Only one video connection per computer is supported.
4) Connected monitors must have HDMI video connection.
