Operations
• Port Selection: Push-buttons, Hotkey, Mouse Whee l(with 3-key USB mouse wheel in emulation mode), Remote Port selector or Mouse cursor (In Matrix Model with Crossover Switching enabled)
• Keyboard Emulation: USB
• Mouse Emulation: USB
• Video Resolution: 4096x2160 @ 60 Hz (4K DCI)
• Scan Interval: 1~255 seconds (5 seconds default)
• Computer Connections: Direct: 2; Daisy Chain or Cascading: 2

Console Connectors
2x HDMI monitors
1x USB Type-A keyboard
1x USB Type-A mouse
2x 3.5mm Jack (green; front and rear) stereo audio
2x 3.5mm Jack (pink; front and rear) microphone
1x 2.5 mm Jack (female) for Remote Port Selector
1x USB 3.0 Type-A (blue; front) for USB peripheral sharing
1x USB 3.0 Type-A (blue; rear) for USB peripheral sharing

CPU Connectors
2x DisplayPort for video
2x USB 3.0 Type-B for keyboard and mouse
2x 3.5mm jack (green) for stereo audio
2x 3.5mm jack (pink) for microphone

Switches
• Port Selection: 3x Push-buttons

Environment/Power
• Operation Temperature: 32~104 F (0~40 C)
• Storage Temperature: -20~60 C
• Humidity: 0~80% RH; Non-condensing
• Power Consumption: DC 12V : 11.58W : 97BTU

Physical
• Housing Case: Metal
• Height: 1.75 in.
• Width: 3.9 in.
• Length: 12.8 in.
• Weight: 1.95 lb
