GCS1953: 3-port, 4K USB-C and DisplayPort hybrid KVMP switch

with Power Delivery and a remote port selector

• Switch and control between two DisplayPort and one USB-C devices/computers from one USB keyboard, mouse and 4K DisplayPort monitor and share two USB peripherals
• Power output allows for USB-C device charging up to 45W¹
• 4K Cinema resolution (4096x2160 @ 60Hz)² with one monitor
• Easily share two USB peripherals across multiple devices
• Includes all necessary cables to get connected and maximize your workstation

Switch and control one USB-C (with DisplayPort Alt Mode) device and two DisplayPort computers from a single USB keyboard, mouse and 4K DisplayPort monitor using IOGEAR's 3-port 4K USB-C KVMP switch.

Perfect setup for anyone who relies on accessing multiple desktops and a USB-C laptop or any USB-C device for work.

GCS1953 3-port USB-C and DisplayPort Hybrid KVMP switch combines KVM a switch with DisplayPort video interface, one USB-C device and 2-port USB 3.1 Gen 1 hub.

The DisplayPort interface provides 4K DCI @ 60Hz resolution that displays the most vivid high-definition images available while producing premium sounds. In addition, the GCS1953 provides USB-C device power delivery 3.0 standard for power supply to the USB-C device.

The GCS1953 allows users to access two DisplayPort computers and one USB-C device from a single USB keyboard and USB mouse. In addition to the front panel push-buttons, remote port selector, and mouse port-switching functionality, the GCS1953 offers hotkeys to help switch ports and configure device settings.

A Power On Detection feature also ensures that if one computer is powered off, the GCS1953 will automatically switch ports to the next powered-on computer.

With a built-in USB 3.1 Gen 1 hub, the GCS1953 provides SuperSpeed 5 Gbps transfer rates to all connected USB peripherals. The unit's independent (asynchronous) switching feature allows the KVM switch's focus to be on one computer while the USB peripheral focus is on another computer. This eliminates the need to purchase a separate USB hub or stand-alone
peripheral sharer such as a print server, modem splitter, etc.

Featuring an unbeatable combination of ultra high 4K resolutions, a next generation USB 3.1 Gen 1 hub and enhanced, user-friendly operations, the GCS1953 delivers the latest
innovations in desktop KVM switching technology.

4K Cinema Clarity Necessary for Many Industries
IOGEAR's 3-port 4K USB-C and DisplayPort KVMP switch delivers clear image resolutions up to 4K Cinema (4096x2160). This switch supports high-resolution graphics that are increasingly necessary in many industries: graphic design, animation studios, healthcare imaging, engineering, finance, government and more.

Easier, More Productive Multi-Tasking
Adding more than one monitor to your perfect setup is easy with a GCS1953 KVMP switch. It supports Multi Stream Transport (MST) which enables you to expand to two DisplayPort monitors.

Email and chat on one screen while working on another. Compare and contrast between two images or documents quickly and intuitively.

Make Your Work Life Easier
KVMPs are the answer to desk clutter. You can switch from each device from the easy-to-use front panel push buttons, hotkeys, mouse and a 6 foot long remote port selector. Your equipment's cords stay in the background, out of the way. Set up your KVMP switch once and quickly connect/disconnect laptops, tablets and phones. Additionally, its fast power-delivery system means there is no need to use the laptop's power cable, you can leave it in your bag.

Multiple Switching Methods
Switch and access up to two DisplayPort computers and one USB-C device from the push-button panel, hotkey combinations on your keyboard or utilize the latest in mouse port-switching functionality to change devices by simply clicking the wheel button on your 3-button USB mouse.

Cost Efficient for Both Home and Office
This TAA-Compliant streamlined solution saves money on desk space as well as additional computer accessories--you only need one keyboard, mouse and monitors. It is perfectly suited for newer laptop (USB-C) and older desktop combinations without the need for an external docking station - so you don't need new equipment.

More Features and Benefits
• DisplayPort 1.2 compliant
• HDCP 1.4 compliant
• Multi Stream Transport (MST) support, enable to expand to two DisplayPort monitors³
• 2-port USB 3.1 Gen 1 for SuperSpeed 5Gbps data transfer rate²
• DisplayPort Alt Mode, enable USB-C connection to carry DisplayPort signals
• Computer selection via front panel pushbutton, hotkeys, mouse4 and remote port selector
• Supports HD Audio⁵
• DisplayPort dual-mode technology (DisplayPort++)⁶
• USB bus-powered⁷
• Firmware upgradable

Package Includes
1x 3-port USB-C and DisplayPort KVMP switch
2x DisplayPort cables
2x USB Type-A to Type-B cables
1x USB Type-C cable
3x 3.5mm speaker cables
1x 6 foot remote port selector
1x Power adapter

Need help with product selection?
Call KVMGalore at 1-800-636-3434, or submit your question on KVMGalore HelpCenter.

1) A connected power adapter is needed on the GCS1953 for USB-C device charging to work
2) For USB-C devices, resolution 4K @ 60Hz when using USB 2.0 transfer rate; 4K @ 30Hz when using USB 3.0 transfer rate
3) First DisplayPort monitor must have DisplayPort 1.2 MST support, second DisplayPort monitor can be DisplayPort 1.1, resolutions will be shared between the two monitors
4) Mouse port switching is only supported under mouse emulation mode with a USB 3-button mouse wheel
5) HD audio through DisplayPort cannot be switched independently
6) DisplayPort signals can be converted to HDMI or DVI
7) The unit can be USB bus-powered by the connected computer sources via USB ports
