DisplayPort HDBaseT Receiver over CAT-5

Model No. 29299 In stock

DisplayPort HDBaseT Receiver over CAT-5
Buy this item and earn 299 ClubPoints.

29299: Extend DisplayPort video and audio signals over a single CAT-5 cable

up to 328 feet at a 1080p video resolution using HDBaseT technology


Note: Transmitter units are purchased separately

The DisplayPort HDBaseT over CAT-5 Extender allows DisplayPort audio/video signals to be extended over a single CAT-5/5e/6 unshielded twisted pair cable up to 328 feet at a 1080p resolution.

C2G DisplayPort HDBaseT extender over CAT-5 is compatible with any operating system and is truly plug and play with no drivers or software required.

C2G DisplayPort HDBaseT extender over CAT-5 utilizes TruChoice™ power, which allows power to be supplied over the CAT-5 cable to both the transmitter and receiver from a single power adapter placed at either the transmitter or the receiver end of the solution. Built-in power surge protection and high ground loop immunity ensure high performance signal extension.

HDBaseT technology supports HDCP and allows the Extended Display Identification Data (EDID) signals, i.e. communication of the display's capabilities to pass through the extension solution ensuring that the content from the source is sent at the optimal resolution for the display.

Features and Benefits
• Extend DisplayPort up to 328 feet at a 1080p resolution
• Utilizes a single category cable for extension
• HDBaseT technology supports HDCP, 3D and EDID pass through
• TruChoice Power only requires a single power adapter at either the transmitter or receiver end
• Warranty : 3 Years

Package Contents
• DisplayPort HDBaseT receiver
• Mounting bracket pack with screws
• User manual
• Foot pad set

Note: Stranded CAT-5e/6 cables may be used for DisplayPort extension applications up to 300 feet. Shielded, solid conductor CAT-5e/6 cabling is recommended for applications where the CAT-5e/6 cable must be coiled, is run near other high-frequency signaling cables or in high EMI/RFI environments. For best performance use CAT-6 solid shielded patch cable.
